Summary
24 hr production: 1030 lb @ 70/50, 827 lb @ 90/70
Dimensions: 22" W x 16.5" D x 29" H
Shipping Carton: 25.5" W x 19.5" D x 34" H
Shipping Weight: 118 lb
Available Condenser Options: Remote Low-Side
Electrical
Base Electrical Ice Head, Volts/Hz/Phase: 115/60/1
Base Electrical Condensing Unit, Volts/Hz/Phase: 208-230/60/1
BTU per hour: 20,000
Max. Fuse Size Ice Head: 15 amps
Max. Fuse Size Condensing Unit: 30 amps
Circuit Wire: 2
Min. Circuit Ampacity Ice Head: Cord
Min. Circuit Ampacity Condensing Unit: 14.5
Energy & Water Usage
Energy: 5.0 kWh/100 lb
Water Usage: 18.0 gallons/100 lb
Technical specs are based on remote-cooled model single-phase.
