Summary
24 hr production: 1775 lb @ 70/50, 1600 lb @ 90/70
Dimensions: 30" W x 24" D x 29" H
Shipping Carton: 34” W x 28” D x 32” H
Shipping Weight: 165 lb / 75 kg
Available Condenser Options: Remote Low-Side
Technical specs shown are based on remote-cooled model single phase.
Electrical
Base Electrical Ice Head, Volts/Hz/Phase: 115/60/1
Base Electrical Condensing Unit, Volts/Hz/Phase: 208-230/60/1
BTU Per Hour: 31,600
Max Fuse Size Ice Head: 15 amps
Max Fuse Size Condensing Unit: 30 amps
Circuit Wire: 3
Min. Circuit Ampacity Ice Head: Cord
Min. Circuit Ampacity Condensing Unit: 19.0
